How many registers does an x86-64 CPU have?

Programming, philosophy, pedaling.

Nov 30, 2020

Tags:

programming,

x86

x86 is back in the general programmer discourse, in part thanks to Apple’s M1 and
Rosetta 2.
As such, I figured I’d do yet another x86-64 post.

Just like the last one,
I’m going to cover a facet of the x86-64 ISA that sets it apart
as unusually complex among modern ISAs: the number and diversity of registers available.

Like instruction counting,
register counting on x86-64 is subject to debates over methodology. In particular, for this blog
post, I’m going to lay the following ground rules:

• I will count sub-registers (e.g., EAX for RAX) as distinct registers. My justification:
  they have different instruction encodings, and both Intel and AMD optimize/pessimize
  particular sub-register use patterns in their microcode.

• I will count registers that are present on x86-64 CPUs, but that can’t be used in long mode.

• I won’t count registers that are only present on older x86 CPUs, like the 80386 and
  80486 test registers.

• I won’t count microarchitectural implementation details, like shadow registers.

• I will count registers that aren’t directly addressable, like MSRs that can only be accessed
  through RDMSR. However, I won’t (or will try not to) double-count registers that
  have multiple access mechanisms (like RDMSR and RDTSC).

• I won’t count model-specific registers that fall into these categories:

  • MSRs that are only present on niche x86 vendors (Cyrix, Via)
  • MSRs that aren’t widely available on recent-ish x86-64 CPUs
    • Errata: I accidentally included AVX-512 in some of the original counts below,
      not realizing that it hadn’t been released on any AMD CPUs. The post has been updated.
  • MSRs that are completely undocumented (both officially and unofficially)

In addition to the rules above, I’m going to use the following considerations and methodology
for grouping registers together:

• Many sources, both official and unofficial, use “model-specific register” as an umbrella term
  for any non-core or non-feature-set register supplied by an x86-64 CPU. Whenever possible, I’ll
  try to avoid this in favor of more specific categories.

• Both Intel and AMD provide synonyms for registers (e.g. CR8 as the “task priority register,” or
  TPR). Whenever possible, I’ll try to use the more generic/category conforming name (like CR8
  in the case above).

• In general, the individual cores of a multicore processor have independent register states.
  Whenever this isn’t the case, I’ll make an effort to document it.

General-purpose registers

The general-purpose registers (or GPRs) are the primary registers in the x86-64 register model.
As their name implies, they are the only registers that are general purpose: each has a set
of conventional uses^{, but programmers are generally free to ignore those conventions and use
them as they please.}

Because x86-64 evolved from a 32-bit ISA which in turn evolved from a 16-bit ISA, each
GPR has a set of subregisters that hold the lower 8, 16 and 32 bits of the full 64-bit
register.

As a table:

Some of the 16-bit subregisters are also special: the original 8086 allowed the high byte
of AX, BX, CX, and DX to be accessed indepenently, so x86-64 preserves this for some
encodings:

So that’s 16 full-width GPRs, fanning out to another 52 subregisters.

Registers in this group: 68.

Running total: 68.

Special registers

This is sort of an artificial category: like every ISA, x86-64 has a few “special” registers that
keep things moving along. In particular:

• The instruction pointer, or RIP.

  x86-64 has 32- and 16-bit variants of RIP (EIP and IP), but I’m not going to count
  them as separate registers: they have identical encodings and can’t be used in the same
  CPU mode^.

• The status register, or RFLAGS.

  Just like RIP, RFLAGS has 32- and 16-bit counterparts (EFLAGS and FLAGS). Unlike
  RIP, these counterparts can be partially mixed: PUSHF and PUSHFQ are both valid in
  long mode, and LAHF/SAHF can operate on the bits of FLAGS on some x86-64 CPUs
  outside of compatiblility mode^{. So I’m going to go ahead and count them.}

Registers in this group: 4.

Running total: 72.

Segment registers

x86-64 has a total of 6 segment registers: CS, SS, DS, ES, FS, and GS. The operation
varies with the CPU’s mode:

• In all modes except for long mode, each segment register holds a selector, which indexes into
  either the GDT or
  LDT. That yields
  a segment descriptor which, among other things, supplies the base address and extent of the
  segment.

• In long mode all but FS and GS are treated as having a base address of zero and a 64-bit
  extent, effectively producing a flat address space. FS and GS are retained as special cases,
  but no longer use the segment descriptor tables: instead, they access base addresses that
  are stored in the FSBASE and GSBASE model-specific registers^{.
  More on those later.}

Registers in this group: 6.

Running total: 78.

SIMD and FP registers

The x86 family has gone through several generations of SIMD and floating-point instruction
groups, each of which has introduced, extended, or re-contextualized various registers:

• x87
• MMX
• SSE (SSE2, SSE3, SSE4, SSE4, …)
• AVX (AVX2, AVX512)

Let’s do them in rough order.

x87

Originally a discrete coprocessor with its own instruction set and register file, the x87
instructions have been regularly baked into x86 cores themselves since the 80486.

Because of its coprocessor history, x87 defines both normal registers
^{(akin to GPRs) and a variety of special registers needed to control the FPU state:}

• ST0 through ST7: 8 80-bit floating-point registers
• FPSW, FPCW, FPTW ^{: Control, status, and tag-word registers}
• “Data operand pointer”: I don’t know what this one does, but the Intel SDM specifies it
• Instruction pointer: the x87 state machine apparently holds its own copy of the current
  x87 instruction
• Last instruction opcode: this is apparently distinct from the x87 opcode, and has its
  own register

Registers in this group: 14.

Running total: 92.

MMX

MMX was Intel’s first attempt at consumer SIMD in their x86 chips, released back in 1997.

For design reasons that are a complete mystery to me, the MMX registers are actually sub-registers
of the x87 STn registers: each 64-bit MMn occupies the mantissa component of its corresponding
STn. Consequently, x86 (and x86-64) CPUs cannot execute MMX and x87 instructions at the same time.

Edit: This section incorrectly included MXCSR, which was actually introduced with SSE.
Thanks to /u/Skorezore for pointing out the error.

Registers in this group: 8.

Running total: 100.

SSE and AVX

For simplicity’s sake, I’m going to wrap SSE and AVX into a single section: they use the same
sub-register pattern as the GPRs and x87/MMX do, so they fit well into a single table:

In other words: the lower half of each ZMMn is YMMn, and the lower half of each YMMn is
XMMn. There’s no direct way register access for just the upper half of YMMn, nor does
ZMMn have direct 256- or 128-bit access for the thunks of its upper half.

SSE also defines a new status register, MXCSR, that contains flags roughly parallel
to the arithmetic flags in RFLAGS (along with floating-point flags in the x87 status word).
SSE also introduces a load/store instruction pair for manipulating it (LDMXCSR and STMXCSR).

AVX-512 also introduces eight opmask registers, k0 through k7. k0 is a special case
that behaves much like the “zero” register on some RISC ISAs: it can’t be stored to, and
loads from it always produce a bitmask of all ones.

Errata: The table above includes AVX-512, which isn’t available on any AMD CPUs as of 2020.
I’ve updated the counts below to only include SSE and AVX2-introduced registers.

Registers in this group: 33.

Running total: 133.

Bounds registers

Intel added these with MPX, which was intended to
offer hardware-accelerated bounds checking. Nobody uses it, since
it doesn’t work very well.
But x86 is eternal and slow to fix mistakes, so we’ll probably have these registers taking up space
for at least a while longer:

• BND0 — BND3: Individual 128-bit registers, each containing a pair of addresses
  for a bound.
• BNDCFG: Bound configuration, kernel mode.
• BNDCFU: Bound configuration, user mode.
• BNDSTATUS: Bound status, after a #BR is raised.

Registers in this group: 7.

Running total: 140.

Debug registers

These are what they sound like: registers that aid and accelerate software debuggers, like
GDB.

There are 6 debug registers of two types:

• DR0 through DR3 contain linear addresses, each of which is associated with a breakpoint
  condition.

• DR6 and DR7 are the debug status and control registers. DR6’s lower bits indicate which
  debug conditions were encountered (upon entering the debug exception handler), while DR7 controls
  which breakpoint addresses are enabled and their breakpoint conditions (e.g., when a particular
  address is written to).

What about DR4 and DR5? For reasons that are unclear to me, they don’t (and have never)
existed^{. They do have encodings but are treated as DR6 and DR7, respective, or produce
an #UD exception when CR4.DE[bit 3] = 1.}

Registers in this group: 6.

Running total: 146.

Control registers

x86-64 defines a set of control registers that can be used to manage and inspect the state of the
CPU.

There are 16 “main” control registers, all of which can be accessed with a
MOV variant:

All reserved control registers result in an #UD when accessed, which makes me inclined to not
count them in this post.

In addition to the “main” CRn control registers there are also the “extended” control registers,
introduced with the XSAVE feature set. As of writing, XCR0 is the only specified extended
control register.

The extended control registers use XGETBV and
XSETBV instead of a MOV variant.

Registers in this group: 6.

Running total: 152.

“System table pointer registers”

That’s what the Intel SDM calls these^{: these registers hold sizes and pointers to various
protected mode tables.}

As best I can tell, there are four of them:

• GDTR: Holds the size and base address of the GDT
• LDTR: Holds the size and base address of the LDT
• IDTR: Holds the size and base address of the IDT
• TR: Holds the TSS selector and base address for the TSS

The GDTR, LDTR, and IDTR each seem to be 80 bits in 64-bit modes: 16 lower bits for
the size of the register’s table, and then the upper 64 bits for the table’s starting address.

TR is likewise 80 bits: 16 bits for the selector (which behaves identically to a segment
selector), and then another 64 for the base address of the TSS^.

Registers in this group: 4.

Running count: 156.

Memory-type-ranger registers

These are an interesting case: unlike all of the other registers I’ve covered so far,
these are not unique to a particular CPU in a multicore chip; instead, they’re shared
across all cores^.

The number of MTTRs seems to vary by CPU model, and have been largely superseded by entries in
the page attribute table, which is programmed
with an MSR^.

Registers in this group:

Running count: >156.

Model specific registers

Model-specific registers are where things get fun.

Like extended control registers, they’re accessed indirectly (by identifier) through a pair
of instructions: RDMSR and WRMSR. MSRs themselves are 64-bits but originated during the
32-bit era, so RDMSR and WRMSR read from and write to two 32-bit registers: EDX and EAX.

By way of example: here’s the setup and RDMSR invocation for accessing the IA32_MTRRCAP MSR,
which includes (among other things) that actual number of MTRRs available on the system:

1
2
3



MOV ECX, 0xFE ; 0xFE = IA32_MTRRCAP
RDMSR
; The bits of IA32_MTRRCAP are now in EDX:EAX

RDMSR and WRMSR are privileged instructions, so normal ring-3 code can’t access MSRs
directly^{. The one (?) exception that I know of is the timestamp counter (TSC),
which is stored in the IA32_TSC MSR but can be read from non-privileged contexts with
RDTSC and RDTSCP.}

Two other interesting (but still privileged^{) cases are FSBASE and GSBASE, which are
stored as IA32_FS_BASE and IA32_GS_BASE, respectively. As mentioned in the segment register
section, these store the FS and GS segment bases on x86-64 CPUs. This makes them targets of
relatively frequent use (by MSR standards), so they have their own dedicated R/W opcodes:}

• RDFSBASE and RDGSBASE for reading
• WRFSBASE and WRGSBASE for writing

But back to the meat of things: how many MSRs are there?

Using the standards laid out at the beginning of this post, we’re interested in counting what
Intel calls “architectural” MSRs. From the SDM^:

Many MSRs have carried over from one generation of IA-32 processors to the next and to Intel
64 processors. A subset of MSRs and associated bit fields, which do not change on future
processor generations, are now considered architectural MSRs. For historical reasons (beginning
with the Pentium 4 processor), these “architectural MSRs” were given the prefix “IA32_”.

According to the subsequent table^{, the highest architectural MSR is 6097/17D1H, or
IA32_HW_FEEDBACK_CONFIG. So, the naïve answer is over 6000.}

However, there are significant gaps in the documented MSR ranges: Intel’s documentation jumps
directly from 3506/DB2H (IA32_THREAD_STALL) to 6096/17D0H (IA32_HW_FEEDBACK_PTR). On
top of the empty ranges, there are also ranges that are explicitly marked as reserved, either
generally or explicitly for later expansion of a particular MSR family.

To count the actual number of MSRs, I did a bit of pipeline ugliness:

• Extract just table 2-2 from Volume 4 of the SDM
  (link):

  1



    $ pdfjam 335592-sdm-vol-4.pdf 19-67 -o 2-2.pdf







• Use pdftotext to convert it to plain text and manually trim the next table from the last page:

  1
  2



    $ pdftotext 2-2.pdf table.txt
    # edit table.txt by hand







• Split the plain text table into a sequence of words, filter by IA32_, remove cruft, and do a
  standard sort-unique-count:

  1
  2
  3
  4
  5
  6



    $ tr -s '[:space:]' '\n' < table.txt \
        | grep 'IA32_' \
        | tr -d '.' \
        | sed 's/\[.*$//' \
        | sort | uniq | wc -l
    404







  (Output preserved for posterity here).

That pipeline left a bit of cruft towards the end thanks to quoted variants, so I count the actual
number at 400 architectural MSRs. That’s a lot more reasonable than 6096!

Registers in this group: 400

Running count: >556.

Other bits and wrapup

The footnotes at the bottom of this post cover most of my notes, but I also wanted to dump some
other resources that I found useful while discovering registers:

• sandpile.org has a nice visualization of many of the
  architectural MSRs, including field breakdowns.

• Vol. 3A § 8.7.1 (“State of the Logical Processors”) of the Intel SDM has a useful list of
  nearly all of the registers that are either unique to or shared between x86-64 cores.

• The OSDev Wiki has collection of helpful pages on various x86-64
  registers, including a great page on the behavior of the segment
  base MSRs.

All told, I think that there are roughly 557 registers on the average (relatively recent)
x86-64 CPU core. With that being said, I have some peripheral cases that I’m not sure about:

• Modern Intel CPUs use integrated
  APICs as part of
  their SMT implementation. These APICs have
  their own register banks which can be
  memory-mapped for reading and potential modification by an x86 core. I didn’t count them because
  (1) they’re memory mapped, and thus behave more like mapped registers from an arbitrary piece of
  hardware than CPU registers, and (2) I’m not sure whether AMD uses the same
  mechanism/implementation.

• The Intel SDM implies that Last Branch Records are stored
  in discrete, non-MSR registers. AMD’s developer manual, on the other hand, specifies a range of
  MSRs. As such, I didn’t attempt to count these separately.

• Both Intel and AMD have their own (and incompatible) virtualization extensions, as well as their
  own enclave/hardened execution extensions. My intuition is that each introduces some additional
  registers (or maybe just MSRs), but their vendor-specificity made me inclined to not look too
  deeply.

Information on these (and any other) registers would be deeply appreciated.

Discussions:

Reddit
