By Jonathan Corbet
April 26, 2024

At the CPU level, a memory model describes, among other things, the amount
of freedom the processor has to reorder memory operations. If low-level
code does not take the memory model into account, unpleasant surprises are
likely to follow. Naturally, different CPUs offer different memory models,
complicating the portability of certain types of concurrent software. To
make life easier, some Arm CPUs offer the ability to emulate the x86 memory
model, but efforts to make that feature available in the kernel are running
into opposition.

CPU designers will do everything they can to improve performance. With
regard to memory accesses, “everything” can include caching operations,
executing them out of order, combining multiple operations into one, and
more. These optimizations do not affect a single CPU running in isolation,
but they can cause memory operations to be visible to other CPUs in a
surprising order. Unwary software running elsewhere in the system may see
memory operations in an order different from what might be expected from
reading the code; this article describes
one simple scenario for how things can go wrong, and this series on lockless algorithms shows in
detail some of the techniques that can be used to avoid problems related to
memory ordering.

The x86 architecture implements a model that is known as “total store
ordering” (TSO), which guarantees that writes (stores) will be seen by all
CPUs in the
order they were executed. Reads, too, will not be reordered, but the
ordering of reads and writes relative to each other is not guaranteed.
Code written for a TSO architecture can, in many cases, omit the use of
expensive barrier instructions that would otherwise be needed to force a
specific ordering of operations.

The Arm memory model, instead, is weaker, giving the CPU more freedom to
move operations around. The benefits from this design are a simpler
implementation and the possibility for better performance in situations
where ordering guarantees are not needed (which is most of the time). The
downsides are that concurrent code can require a bit more care to write
correctly, and code written for a stricter memory model (such as TSO) will
have (possibly subtle) bugs when run on an Arm CPU.

The weaker Arm model is rarely a problem, but it seems there is one
situation where problems arise: emulating an x86 processor. If an x86
emulator does not also emulate the TSO memory model, then concurrent code
will likely fail, but emulating TSO, which requires inserting memory
barriers, creates a significant performance
penalty. It seems that there is one type of concurrent x86 code — games —
that some users of Arm CPUs would like to be able to run; those users,
strangely, dislike the prospect of facing the orc hordes in the absence of
either performance or correctness.

TSO on Arm

As it happens, some Arm CPU vendors understand this problem and have, as
Hector Martin described in this
patch series, implemented TSO memory models in their processors. Some
NVIDIA and Fujitsu CPUs run with TSO at all times; Apple’s CPUs provide it
as an optional feature that can be enabled at run time. Martin’s purpose
is to make this capability visible to, and controllable by, user space.

The series starts by adding a couple of new prctl()
operations. PR_GET_MEM_MODEL will return the current memory model
implemented by the CPU; that value can be either
PR_SET_MEM_MODEL_DEFAULT or PR_SET_MEM_MODEL_TSO. The
PR_SET_MEM_MODEL operation will attempt to enable the requested
memory model, with the return code indicating whether it was successful;
it is allowed to select a stricter memory model than requested. For the
always-TSO CPUs, requesting TSO will obviously succeed. For Apple CPUs,
requesting TSO will result in the proper CPU bits being set. Asking for
TSO on a CPU that does not support it will, as expected, fail.

Martin notes that the code is not new: “This series has been brewing in
the downstream Asahi Linux tree for a while now, and ships to thousands of
users“. Interestingly, Zayd Qumsieh had posted a
similar patch set one day earlier, but that version only implemented
the feature for Linux running in virtual machines on Apple CPUs.

Unfortunately for people looking forward to faster games on Apple CPUs,
neither patch set is popular with the maintainers of the Arm architecture
code in the kernel. Will Deacon expressed
his “strong objection“, saying that this feature would result in a
fragmentation of user-space code. Developers, he said, would just enable
the TSO bit if it appears to make problems go away, resulting in code that
will fail, possibly in subtle ways, on other Arm CPUs. Catalin Marinas,
too, indicated
that he would block patches making this sort of implementation-defined
feature available.

Martin responded
that fragmentation is unlikely to be a problem, and pointed to the
different page sizes supported by some processors (including Apple’s) as an
example of how these incompatibilities can be dealt with. He said that, so
far, nobody has tried to use the TSO feature for anything that is not an
emulator, so abuse in other software seems unlikely. Keeping it out, he
said, will not improve the situation:

There’s a pragmatic argument here: since we need this, and it
absolutely will continue to ship downstream if rejected, it doesn’t
make much difference for fragmentation risk does it? The vast
majority of Linux-on-Mac users are likely to continue running
downstream kernels for the foreseeable future anyway to get newer
features and hardware support faster than they can be
upstreamed. So not allowing this upstream doesn’t really change the
landscape vis-a-vis being able to abuse this or not, it just makes
our life harder by forcing us to carry more patches forever.

Deacon, though, insisted
that, once a feature like this is merged, it will find uses in other
software “and we’ll be stuck supporting it“.

If this patch is not acceptable, it is time to think about alternatives.
One is to, as Martin described, just keep it out-of-tree and ship it on the
distributions that actually run on that hardware. A long history of
addition by distributions can, at times, eventually ease a patch’s way past
reluctant maintainers. Another might be to just enable TSO unconditionally
on Apple CPUs, but that comes with an overall performance penalty — about
9%, according
to Martin. Another possibility was mentioned by Marc
Zyngier, who suggested that virtual machines could be started with TSO
enabled, making it available to applications running within while keeping the
kernel out of the picture entirely.

This seems like the kind of discussion that does not go away quickly.
One of the many ways in which Linux has stood out over the years is in its
ability to allow users to make full use of their hardware; refusing to
support a useful hardware feature runs counter to that history. The
concerns about potential abuse of this feature are also based in long
experience, though. This is a case where the development community needs
to repeat another part of its long history by finding a solution that
makes the needed functionality available in a supportable way.
