x011/smtp-tunnel-proxy: A high-speed covert tunnel that disguises TCP traffic as SMTP email communication to bypass Deep Packet Inspection (DPI) firewalls.

A high-speed covert tunnel that disguises TCP traffic as SMTP email communication to bypass Deep Packet Inspection (DPI) firewalls.

┌─────────────┐      ┌─────────────┐      ┌─────────────┐      ┌──────────────┐
│ Application │─────▶│   Client    │─────▶│   Server    │─────▶│  Internet    │
│  (Browser)  │ TCP  │ SOCKS5:1080 │ SMTP │  Port 587   │ TCP  │              │
│             │◀─────│             │◀─────│             │◀─────│              │
└─────────────┘      └─────────────┘      └─────────────┘      └──────────────┘
                            │                    │
                            │   Looks like       │
                            │   Email Traffic    │
                            ▼                    ▼
                     ┌────────────────────────────────┐
                     │     DPI Firewall               │
                     │  ✅ Sees: Normal SMTP Session  │
                     │  ❌ Cannot see: Tunnel Data    │
                     └────────────────────────────────┘

📚 For in-depth technical details, protocol specifications, and security analysis, see TECHNICAL.md.

• Server: Linux VPS with Python 3.8+, port 587 open
• Client: Windows/macOS/Linux with Python 3.8+
• Domain name: Required for TLS certificate verification (free options: DuckDNS, No-IP, FreeDNS)

Get a free domain pointing to your VPS:

• 🦆 DuckDNS – Recommended, simple and free
• 🌐 No-IP – Free tier available
• 🆓 FreeDNS – Many domain options

Example: myserver.duckdns.org → 203.0.113.50 (your VPS IP)

curl -sSL https://raw.githubusercontent.com/x011/smtp-tunnel-proxy/main/install.sh | sudo bash

The installer will:

1. 📥 Download and install everything
2. ❓ Ask for your domain name
3. 🔐 Generate TLS certificates automatically
4. 👤 Offer to create your first user
5. 🔥 Configure firewall
6. 🚀 Start the service

That’s it! Your server is ready.

smtp-tunnel-adduser bob      # Add user + generate client ZIP
smtp-tunnel-listusers        # List all users
smtp-tunnel-deluser bob      # Remove a user

smtp-tunnel-update           # Updates code, preserves config/certs/users

1. Get your username.zip file from the server admin
2. Extract the ZIP file
3. Run the launcher:

The launcher will automatically install dependencies and start the client.

✅ You should see:

SMTP Tunnel Proxy Client
User: alice

[INFO] Starting SMTP Tunnel...
[INFO] SOCKS5 proxy will be available at 127.0.0.1:1080

Connecting to myserver.duckdns.org:587
Connected - binary mode active
SOCKS5 proxy on 127.0.0.1:1080

cd alice
pip install -r requirements.txt
python client.py

# Download files
scp root@myserver.duckdns.org:/etc/smtp-tunnel/ca.crt .

# Create config.yaml:
cat > config.yaml << EOF
client:
  server_host: "myserver.duckdns.org"
  server_port: 587
  socks_port: 1080
  username: "alice"
  secret: "your-secret-from-admin"
  ca_cert: "ca.crt"
EOF

# Run client
python client.py -c config.yaml

Set SOCKS5 proxy to: 127.0.0.1:1080

1. Settings → Network Settings → Settings
2. Manual proxy configuration
3. SOCKS Host: 127.0.0.1, Port: 1080
4. Select SOCKS v5
5. ✅ Check “Proxy DNS when using SOCKS v5”

1. Install “Proxy SwitchyOmega” extension
2. Create profile with SOCKS5: 127.0.0.1:1080

Settings → Network & Internet → Proxy → Manual setup → socks=127.0.0.1:1080

System Preferences → Network → Advanced → Proxies → SOCKS Proxy → 127.0.0.1:1080

export ALL_PROXY=socks5://127.0.0.1:1080

# curl
curl -x socks5h://127.0.0.1:1080 https://ifconfig.me

# git
git config --global http.proxy socks5://127.0.0.1:1080

# Environment variable
export ALL_PROXY=socks5://127.0.0.1:1080

# Should show your VPS IP
curl -x socks5://127.0.0.1:1080 https://ifconfig.me

Each user can have individual settings:

users:
  alice:
    secret: "auto-generated-secret"
    # whitelist:              # Optional: restrict to specific IPs
    #   - "192.168.1.100"
    #   - "10.0.0.0/8"        # CIDR notation supported
    # logging: true           # Optional: disable to stop logging this user

  bob:
    secret: "another-secret"
    whitelist:
      - "203.0.113.50"        # Bob can only connect from this IP
    logging: false            # Don't log Bob's activity

# Check status
sudo systemctl status smtp-tunnel

# Restart after config changes
sudo systemctl restart smtp-tunnel

# View logs
sudo journalctl -u smtp-tunnel -n 100

# Uninstall
sudo /opt/smtp-tunnel/uninstall.sh

python server.py [-c CONFIG] [-d]

  -c, --config    Config file (default: config.yaml)
  -d, --debug     Enable debug logging

python client.py [-c CONFIG] [--server HOST] [--server-port PORT]
                 [-p SOCKS_PORT] [-u USERNAME] [-s SECRET] [--ca-cert FILE] [-d]

  -c, --config      Config file (default: config.yaml)
  --server          Override server domain
  --server-port     Override server port
  -p, --socks-port  Override local SOCKS port
  -u, --username    Your username
  -s, --secret      Override secret
  --ca-cert         CA certificate path
  -d, --debug       Enable debug logging

smtp-tunnel-adduser <username> [-u USERS_FILE] [-c CONFIG] [--no-zip]
    Add a new user and generate client package

smtp-tunnel-deluser <username> [-u USERS_FILE] [-f]
    Remove a user (use -f to skip confirmation)

smtp-tunnel-listusers [-u USERS_FILE] [-v]
    List all users (use -v for detailed info)

smtp-tunnel-update
    Update server to latest version (preserves config/certs/users)

smtp_proxy/
├── 📄 server.py               # Server (runs on VPS)
├── 📄 client.py               # Client (runs locally)
├── 📄 common.py               # Shared utilities
├── 📄 generate_certs.py       # Certificate generator
├── 📄 config.yaml             # Server/client configuration
├── 📄 users.yaml              # User database
├── 📄 requirements.txt        # Python dependencies
├── 📄 install.sh              # One-liner server installer
├── 📄 smtp-tunnel.service     # Systemd unit file
├── 🔧 smtp-tunnel-adduser     # Add user script
├── 🔧 smtp-tunnel-deluser     # Remove user script
├── 🔧 smtp-tunnel-listusers   # List users script
├── 🔧 smtp-tunnel-update      # Update server script
├── 📄 README.md               # This file
└── 📄 TECHNICAL.md            # Technical documentation

/opt/smtp-tunnel/              # Application files
/etc/smtp-tunnel/              # Configuration files
  ├── config.yaml
  ├── users.yaml
  ├── server.crt
  ├── server.key
  └── ca.crt
/usr/local/bin/                # Management commands
  ├── smtp-tunnel-adduser
  ├── smtp-tunnel-deluser
  ├── smtp-tunnel-listusers
  └── smtp-tunnel-update

• Check server is running: systemctl status smtp-tunnel or ps aux | grep server.py
• Check port is open: netstat -tlnp | grep 587
• Check firewall: ufw status

• Verify username and secret match in users.yaml
• Check server time is accurate (within 5 minutes)
• Run smtp-tunnel-listusers -v to verify user exists

• Check user’s whitelist in users.yaml
• Your current IP must match a whitelist entry
• CIDR notation is supported (e.g., 10.0.0.0/8)

• Ensure you’re using a domain name, not IP address
• Verify server_host matches the certificate hostname
• Ensure you have the correct ca.crt from the server

# Enable detailed logging
python server.py -d
python client.py -d

# View systemd logs
journalctl -u smtp-tunnel -f

• ✅ Always use a domain name for proper TLS verification
• ✅ Always use ca_cert to prevent man-in-the-middle attacks
• ✅ Use smtp-tunnel-adduser to generate strong secrets automatically
• ✅ Use per-user IP whitelists if you know client IPs
• ✅ Protect users.yaml – contains all user secrets (chmod 600)
• ✅ Disable logging for sensitive users with logging: false

📚 For detailed security analysis and threat model, see TECHNICAL.md.

This project is provided for educational and authorized use only. Use responsibly and in accordance with applicable laws.

This tool is designed for legitimate privacy and censorship circumvention purposes. Users are responsible for ensuring their use complies with applicable laws and regulations.

Made with ❤️ for internet freedom
