xaskasdf/ntransformer: High-efficiency LLM inference engine in C++/CUDA. Run Llama 70B on RTX 3090.

High-efficiency C++/CUDA LLM inference engine. Runs Llama 70B on a single RTX 3090 (24GB VRAM) by streaming model layers through GPU memory via PCIe, with optional NVMe direct I/O that bypasses the CPU entirely.

3-tier adaptive caching auto-sizes from hardware: VRAM-resident layers (zero I/O) + pinned RAM (H2D only) + NVMe/mmap fallback. Achieves 83x speedup over mmap baseline for 70B on consumer hardware (RTX 3090 + 48 GB RAM).

Bottleneck is PCIe H2D bandwidth at Gen3 x8 (~6.5 GB/s). Q4_K_M fits 10 more layers in VRAM (36 vs 26), reducing tier B transfers. Layer skip (cosine similarity calibration) eliminates 20/80 layers per token with minimal quality loss.

• Zero external dependencies beyond CUDA Toolkit (no PyTorch, no cuBLAS)
• GGUF model format with Q4_0, Q8_0, Q4_K_M, Q5_K, Q6_K, F16, F32 quantization
• 3-Tier Adaptive Caching: auto-sized VRAM resident + pinned RAM + NVMe/mmap tiers
• SLEP streaming: double-buffered layer pipeline overlaps NVMe reads, PCIe DMA, and GPU compute
• gpu-nvme-direct backend: userspace NVMe driver reads model weights directly to pinned GPU-accessible memory
• Layer skip: cosine-similarity calibration skips redundant layers (20/80 skipped at threshold 0.98)
• Self-speculative decoding: VRAM-resident layers as draft model (no extra model needed)
• Four data paths (auto-selected): VRAM resident > pinned RAM H2D > mmap pinned > CPU worker memcpy
• Llama architecture: RoPE, GQA, SwiGLU, RMSNorm, KV cache

• Linux (tested on Ubuntu, kernel 6.17+)
• CUDA Toolkit 13.1
• gcc-14 / g++-14
• NVIDIA GPU with Compute Capability 8.0+ (RTX 3090 tested)
• CMake 3.24+
• (Optional) NVMe SSD on separate PCIe slot + gpu-nvme-direct library

# Build
mkdir build && cd build
cmake .. -DCMAKE_BUILD_TYPE=Release \
  -DCMAKE_C_COMPILER=gcc-14 \
  -DCMAKE_CXX_COMPILER=g++-14 \
  -DCMAKE_CUDA_COMPILER=/usr/local/cuda-13.1/bin/nvcc
cmake --build . -j

# Run (resident mode — model fits in VRAM)
./ntransformer -m /path/to/llama-8b-q8_0.gguf -p "Hello" -n 128

# Run (streaming mode — model larger than VRAM)
./ntransformer -m /path/to/llama-70b-q6_k.gguf -p "Hello" -n 32 --streaming

# Run with layer skip (fastest for 70B)
./ntransformer -m /path/to/llama-70b-q4_k_m.gguf -p "Hello" -n 32 --streaming --skip-threshold 0.98

# Self-speculative decoding (VRAM layers as draft, no extra model)
./ntransformer -m /path/to/llama-70b-q6_k.gguf -p "Hello" -n 32 --self-spec --draft-k 3

# Chat mode
./ntransformer -m /path/to/model.gguf --chat

# Benchmark
./ntransformer -m /path/to/model.gguf --benchmark -n 64

Running ntransformer with NVMe direct I/O requires system-level modifications. An automated setup script handles all of them:

# Full first-time setup (interactive, creates backups)
sudo ./scripts/setup_system.sh

# Check current system state (no changes)
sudo ./scripts/setup_system.sh --check

# NVMe-only (run after every reboot)
sudo ./scripts/setup_system.sh --nvme-only

• Above 4G Decoding: ON (required for 64-bit BAR mapping)
• IOMMU: OFF (or leave on — the script adds the kernel parameter)
• Secure Boot: OFF (required for unsigned/patched kernel module loading)

WARNING: This project performs low-level PCIe operations (GPU MMIO writes to NVMe controller
registers, userspace NVMe command submission, VFIO device passthrough). While tested extensively on
RTX 3090 + WD SN740, incorrect configuration or hardware incompatibilities could theoretically cause:

• NVMe link failure requiring power cycle (observed during development with GPU reads)
• Data loss on the NVMe device used for raw block storage
• System instability from disabled IOMMU or patched kernel modules

Never use your boot drive for NVMe direct I/O. Always use a dedicated secondary NVMe.
The authors are not responsible for hardware damage or data loss. Use at your own risk.

For models that don’t fit in VRAM, the NVMe backend eliminates the CPU from the data path:

NVMe SSD → (DMA) → Pinned Staging → (PCIe H2D) → GPU Buffers → Compute

# Build with NVMe support (requires gpu-nvme-direct library)
cmake .. -DCMAKE_BUILD_TYPE=Release -DUSE_GPUNVME=ON \
  -DCMAKE_C_COMPILER=gcc-14 -DCMAKE_CXX_COMPILER=g++-14 \
  -DCMAKE_CUDA_COMPILER=/usr/local/cuda-13.1/bin/nvcc
cmake --build . -j

# Write GGUF model to NVMe raw device
sudo ./scripts/restore_nvme.sh           # ensure kernel driver is bound
sudo dd if=model.gguf of=/dev/nvme0n1 bs=1M oflag=direct status=progress

# Bind NVMe to VFIO for userspace access
sudo ./scripts/setup_nvme.sh             # loads VFIO, forces D0, enables BusMaster

# Run with NVMe backend
sudo GPUNVME_PCI_BDF=0000:01:00.0 GPUNVME_GGUF_LBA=0 \
  ./build/ntransformer -m /path/to/model.gguf -p "Hello" -n 32 --streaming

# Restore NVMe to kernel driver when done
sudo ./scripts/restore_nvme.sh

1. The GGUF model file is written to raw NVMe blocks via dd
2. setup_nvme.sh binds the NVMe to VFIO, forces PCIe D0 power state, enables BusMaster
3. gpu-nvme-direct initializes the NVMe controller from userspace (admin queues, I/O queues)
4. During inference, each layer (~670 MB for 70B Q6_K) is read via 670 NVMe commands in ~202 ms
5. Data lands in CUDA pinned staging memory, then async DMA to GPU compute buffers
6. Pipeline overlaps NVMe reads, H2D DMA, and GPU compute across double buffers

src/
├── core/           # Tensor, allocator, GPU device management
├── cuda/           # CUDA kernels: GEMV, RMSNorm, RoPE, SwiGLU, softmax
├── memory/         # SLEP layer streaming engine (NVMe + mmap backends)
├── model/          # Transformer: config, GGUF loader, attention, FFN, norms
├── inference/      # Tokenizer, sampler, engine
├── utils/          # Timer, logger
├── main.cpp        # CLI entry point
scripts/
├── setup_system.sh # Full system setup (GRUB, NVIDIA patch, CUDA patch, VFIO, NVMe)
├── setup_nvme.sh   # Bind NVMe to VFIO, configure for gpu-nvme-direct
├── restore_nvme.sh # Restore NVMe to kernel driver
tests/              # Unit tests (tensor, GEMM kernels, NVMe layer loader)

forward_tiered() — hybrid pipeline:

Tier A (VRAM resident, layers 0..28):
  GPU Compute:  [layer 0][layer 1]...[layer 28]     (zero I/O, weights permanent)

Tier B (pinned RAM, layers 29..79, double-buffered):
  H2D DMA:     [L29→gpu0][L30→gpu1][L31→gpu0]...   (async from pinned RAM)
  GPU Compute: [         ][layer 29][layer 30]...    (overlapped with H2D)

Tier C (NVMe/mmap fallback, if needed):
  NVMe/memcpy: [read L→stg0][read L→stg1]...
  H2D DMA:     [            ][stg0→gpu0  ]...
  GPU Compute: [            ][            ][layer]...

Tier sizes auto-computed from cudaMemGetInfo() + /proc/meminfo MemAvailable.

• Phase 1 – Foundation (complete): Llama 8B Q8_0, custom CUDA kernels, 48.9 tok/s
• Phase 2 – SLEP Streaming (complete): 70B on single GPU, 3-tier caching, 33x speedup
• Phase 3 – Optimization (complete): Q4_K_M/Q5_K support, layer skip (0.5 tok/s), self-speculative decoding, F16 KV cache
• Phase 4 – NVMe Direct: gpu-nvme-direct backend for tier C (GPU-initiated NVMe reads, 3.35 GB/s)
• Phase 5 – Polish: speculative decoding with draft model, benchmarks, public C API

BSD-2-Clause
